Features
- 963CC V-TWIN: The CFORCE 1000 Overland is powered by a 84-horsepower, 963cc V-Twin bringing the ultimate combination of durability and performance to the trails. The liquid-cooled 8-valve engine with EFI features crisp, consistent power throughout the rpm range, ensuring the robust 62 lb-ft of torque at 5500 rpm has the muscle to take on any size adventure at any elevation.
- REMOVABLE HARD-SIDE TRAVEL CASES: Head out for your multi-day Overland experience with plenty of room for everything you need. Two premium cargo boxes install easily without any modification and provide gallons of combined storage space. Weather resistance means your belongings stay dry and protected from water and dust.
- 3,500 LB. WINCH WITH SYNTHETIC ROPE: This heavy-duty winch features synthetic rope, a lighter, stronger, safer alternative to steel cable. What’s more, it’s far easier to handle. Especially when you’re working fast.
- ALUMINUM ALLOY WHEELS WITH BEADLOCK RIMS: Lightweight aluminum wheels and rugged 27” CST Clincher off-road tires on 14-inch beadlock rims ensure you’ll be ready when nature gets nasty.
- FRONT FAIRING: The front fairing features an integrated windscreen and hand guards, protecting you from the elements while providing optimal visibility.
Specifications
General Information
Manufacturer
CFMOTO
Model Year
2025
Model
CForce 1000 Overland
Model Code
CF1000AZ
Color
Forest Green
Brakes/Wheels/Tires
Brakes
Front / Rear – Hydraulic disc with parking
Wheels
Front / Rear – 14 in. Cast aluminum alloy with bead lock
Tires
Front 27 x 9 in. x R14
Rear – 27 x 11 in. x R14 CST Clincher
Dimensions
Length
92 in.
Height
53 in.
Width
50 in.
Weight
Dry – 975 lb.
Ground Clearance
12 in.
Wheelbase
58 in.
Seat Height
22 in.
Turning Radius
10.9 ft.
Drivetrain
Transmission
OmniDrive™ CVT P / R / N / H / L
Drive
2WD / 4WD / 4WD lock
Electrical
Instrumentation
7 in. TFT Display
Lighting
CFMOTO LED™ Headlights and Taillights with Daytime Running Lights
LED Floodlights
Advanced Electronics
Bluetooth Call Indicator
Engine
Engine
V-twin, 4-stroke, SOHC, 8-valve
Cooling
Liquid
Horsepower
Max – 84 hp @ 7,500 rpm
Displacement
963 cc
Torque
Max – 62 ft. lb. @ 5,500 rpm
Fuel System
Bosch® EFI with Work / Normal / Sport Modes
Starting
Electric
Fuel Capacity
6.9 gal.
Operational
Suspension
Front – High clearance A-arm, independent
Rear – Trailing arm independent
Front / Rear shocks – High pressure gas with piggyback reservoir, compression and rebound adjustable
Front / Rear travel – 9 in.
Steering
Brushless electronic power
Adjustable Electronic Power
Hitch
2 in. receiver
Towing Capacity
1,800 lb.
Winch – 3,500 lb. with Synthetic Rope
Capacity
Front rack – 99 lb.
Rear rack – 198 lb.
Other
Additional Colors
Desert Tan
Forest Green
Includes
Steel Racks with Composite Cover, Hand Guards, Windshield, Fender Flares, Front Bumpers, 12V Outlet and USB Port, Downhill Assist Control
Vehicle Safety – Safety is our number one priority at CFMOTO, and we want to ensure all our riders are having both an exciting and safe experience. Learn about our safety training courses, proper riding attire, and best riding practices on our Vehicle Safety page.
Warranty
4 year factory
